High Low Thread Slotted Hex Head Concrete Screws Blue Coating
High Low Thread Concrete screws are designed with a high and low thread to cut the concrete more effectively and to keep its alignment. High Low Thread Concrete screws is made of tempered, high grade steel to ensure the best torque and maximum holding power and is coated with the corrosion resistant Blue coating.
Our High Low Thread Concrete screws are ICC-ES approved, ACQ compatible and is offered with a flat or a hexagonal head. The hexagonal head style contains a drill bit in the 10-piece pack, while a drill bit is included in packs of 25 and 100 pieces. The hexagonal head concrete screws are available in sizes ranging from 3/16" x 1-1/4" to 1/4" x 5".
High Low Thread Self Tapping Concrete screws Key Features:
▶ Material: Carbon Steel
▶ HIGH GRADE HEAT TREATED STEEL to ensure the best torque, pull and shear performance.
▶ Blue Fluorocarbon coating to maximize corrosion resistance, more than 1000 hours of salt spray test.
▶ HIGH & LOW THREAD for an ease of installation and maximum holding power.
▶ COMBINED FLAT HEAD (Robertson & Philips), for a better grip and superior efficiency.
▶ HEXAGONAL HEAD (Hexagonal & slot).
▶ Compatible with ACQ (Alkaline Copper Quaternary), an environmentally friendly water-based preservative used for pressure
treated lumber.
High Low Thread Self Tapping Concrete screws Specifications:
Available Diamter: 3/16" & 1/4" (4.8 mm & 6.4 mm)
Screw Lengths Available: 3/16" : from 1-1/4" to 4" (4.8 mm : from 31.7 mm to 101.6 mm) in 1/4" : from 1-1/4" to 6" (6.4 mm : from 31.7 mm to 152.4 mm)
Type of heads: FLAT OR HEXAGONAL HEAD, THE LOAD WEIGHTS ARE THE SAME.
Finishing: Blue Evoshield 500Hr NSST (Neutral Salt Spray Test)
Customized High Low Thread Self Tapping Concrete screws for Concrete Assortment Kit.
We can packed the High Low Thread Self Tapping Concrete screws in customization set, in plastic box or colorful box. Due to tariff and material increases, please consult us for details to get the latest and most accurate prices.
High Low Thread Self Tapping Concrete screws Application:
Concrete screws are specialized fasteners designed to anchor objects securely into concrete, brick, or block. They are widely used in construction, DIY projects, and industrial applications due to their strength and ease of installation. Here are common applications:
1.General Construction and Framing
Fixing wood or metal studs to concrete floors or walls
Securing bottom or top plates for wall framing
Installing sill plates for decks or sheds
2. Electrical and Plumbing Work
Mounting conduit straps junction boxes or pipe hangers on concrete
Attaching cable trays in industrial areas
3. HVAC and Mechanical Systems
Anchoring ductwork vents or equipment brackets to masonry
Installing wall mounted air conditioning units
4. Indoor and Outdoor Fixtures
Hanging drywall tracks on concrete ceilings or walls
Attaching baseboards trim or crown molding to masonry
Securing shelves cabinets or TV mounts in basements or garages
